183 Products
MASERATI Car Parts
Maserati parts selection begins with generation, body and complete drivetrain. Ghibli has described both historic and modern vehicles; Quattroporte spans several saloon generations; GranTurismo and Levante add different transaxle, automatic, Q4 and suspension systems. Record the VIN, build date, model/chassis code, engine, gearbox, driven axles, brake and damper options, then compare installed labels, connectors and dimensions.
Petrol engines vary by naturally aspirated, twin-turbo and later electrified design, with different timing, fuel pressure, ignition, oil and cooling. Diesel variants add common-rail, turbo, EGR, DPF and SCR equipment according to emissions stage. Historic engines and carburettor/injection systems require their own timing and fastener data; capacity or cylinder count cannot confirm service parts.
Automatic, automated-manual/transaxle and other modern gearboxes have separate clutches, hydraulics, filters, fluids and adaptation. Q4 all-wheel drive adds a transfer unit, front drive, differentials and control hardware that vary by model. Select lubricant by the exact casing and fill process. Keep tyre size, construction, wear and pressure compatible across controlled axles.
Skyhook-style electronic damping, conventional springs and Levante air-suspension equipment require option-specific dampers, sensors and calibration. A low air-sprung corner can result from a bag/strut, pipe, valve, compressor, sensor or linkage. Support the structure independently and depressurise through the diagnostic procedure before opening a line.
Brake packages vary by model, engine, wheel and option. Confirm disc diameter, thickness, offset, direction, caliper/piston arrangement, pad contour and wear lead. Electronic parking brakes require the correct service mode. Match wheels by width, offset, centre bore, fastener seat, load and brake clearance; appearance cannot establish capacity.
Diagnose oil/coolant warnings, boost loss, gearbox faults, Q4 binding, ride-height or ADAS messages from complete data and mechanical tests. Restore heat shields, undertrays, brake ducts, clips and grounds, then initialise parking brake, suspension, steering and cameras/radar. Do not drive with brake/steering defects, tyre damage, overheating, fuel/oil leaks, red warnings, unstable gearbox engagement or unsafe height; repair or recover before UK road or MOT use.
Your Current Vehicle
Or
Select Your Vehicle
Shop Parts by Category
Choose a category to view parts for your selected vehicle.
Vehicle Models and Options for MASERATI
MASERATI Car Part Categories
Only categories with verified fitment products are shown.
MASERATI Parts Catalogue Online
Browse catalogue-backed parts by vehicle system.
A familiar model name can hide a different era
Historic and modern Ghibli vehicles are not successive facelifts of one platform. Quattroporte likewise crosses multiple generations, while GranTurismo and Levante follow their own packaging. The first decision is chassis and build date.
Capture VIN, model code, body, engine, gearbox and driven axles. Include brake, wheel, damper and air-suspension option data, then inspect the actual assembly where prior upgrades may be present.
Identity should be confirmed at each mechanical interface
| Interface | Evidence required | Possible mismatch |
|---|---|---|
| Engine to body | Engine code, mount, sump and cooling route. | Same capacity with another installation. |
| Engine to gearbox | Bellhousing, flywheel/converter and control generation. | Different clutch or torque capacity. |
| Gearbox to axle | Transmission, transaxle, transfer and shaft labels. | Ratio or flange incompatibility. |
| Hub to brake | Disc, caliper, offset and wheel option. | Contact or incorrect thermal capacity. |
| Body to suspension | Spring/air, damper and height sensor option. | Wrong valving, stroke or calibration. |
| Sensor to network | Part number, connector, software and coding. | Signal range or configuration error. |
Historic Ghibli needs chassis-era service data
A historic Ghibli uses different structure, engine management, brakes and fasteners from the modern saloon. Carburettor or period injection, ignition advance, turbo equipment and cooling should be identified from engine/chassis numbers and installed hardware.
Age also makes previous modifications likely. Document fuel hose, ignition, wheel, brake and suspension changes. Do not apply a modern Ghibli diagnostic or lubricant assumption to a classic drivetrain.
Modern Ghibli and Quattroporte split by engine and Q4
Modern saloons can be rear-wheel drive or Q4 all-wheel drive, with petrol, diesel or later electrified powertrains according to model/year. Front differential, transfer unit, sump, shafts and steering components can change with Q4 packaging.
Full engine code establishes turbo, injection, timing, emissions and oil specification. Output badge is insufficient because software and hardware revisions do not always align with exterior trim.
GranTurismo gearbox location changes the torque path
GranTurismo derivatives can use conventional automatic or electro-actuated manual/transaxle arrangements depending on generation and specification. A rear transaxle changes torque tube/shaft, clutch actuation and weight distribution compared with a front gearbox.
Identify gearbox location and label before selecting clutch, fluid, filter or driveshaft. Automated clutch learning should only follow checks of wear, hydraulic pressure, actuator movement and battery supply.
Secure the vehicle during actuator procedures
Gear or clutch engagement can occur while learning. Use wheel restraint, correct lift state and stable voltage. Keep people clear of driven wheels and do not repeat a failed procedure until its fault is understood.
Powertrain type determines test priorities
| Powertrain | Identification focus | Diagnostic priority |
|---|---|---|
| Naturally aspirated petrol | Engine code, timing, injection and exhaust. | Compression, fuel trims, ignition and cam data. |
| Twin-turbo petrol | Turbo arrangement, cooling, fuel pressure and oil. | Leaks, control, temperature and lubrication. |
| Diesel | Injection, turbo, EGR, DPF and SCR stage. | Supply, correction, boost and regeneration data. |
| Mild hybrid | Starter-generator, battery voltage and DC-DC system. | Both electrical supplies, belt and thermal control. |
| Battery electric | Battery, inverter, motors, charger and reduction gears. | High-voltage isolation and thermal systems. |
| Q4 AWD | Transfer, front differential, ratios and tyres. | Wheel speeds, clutch command and fluid. |
Timing architecture varies across engine generations
Maserati engines use different belt or chain systems, tensioners and cam-control hardware. Older turbo engines and modern V6/V8 units require unrelated locking datum and replacement scope. Identify the complete engine before selecting a kit.
Investigate rattle or correlation faults with oil pressure, guides, tensioners, phasers and sensor data. Correct leaks, renew specified bolts and rotate manually before first start.
Oil and cooling protect turbo and timing hardware
Use the exact oil approval, viscosity, filter and level method. Turbo bearings and cam control depend on clean flow. Stop immediately for pressure warnings, heavy oil smoke or uncontrolled engine speed.
Cooling can include engine, charge-air, gearbox and hybrid circuits. Trace reservoirs and pumps. Use the specified coolant and diagnostic bleed routine. Pressure-test cold and never release a hot cap.
Diesel aftertreatment is an engine-system result
DPF loading depends on combustion quality, temperature and valid pressure sensors. SCR adds dosing and NOx control where fitted. A thermostat, injector or boost leak can create repeated filter warnings.
Save soot, regeneration and restart-limit data. Avoid forced regeneration with excess oil level, fuel leak or implausible temperatures. Required emissions devices must remain functional.
Q4 service begins with tyres and ratio data
Q4 systems control front-axle torque through model-specific transfer and differential hardware. Front/rear ratios must agree and shafts must match length and flange. Oil selection follows the exact unit.
Closely match tyre size, make/model where required, wear and pressure. If binding or warnings begin after tyre replacement, measure rolling circumference and wheel-speed data before condemning the transfer unit.
Automatic and transaxle fluids are not transferable
Torque-converter automatics, electro-actuated manuals and modern dual-clutch/electric reduction systems use different lubricants and fill states. Fluid colour is not a specification. Level can depend on temperature and selector/actuator sequence.
Keep drain/fill points clearly identified and preserve magnetic debris for diagnosis. Additives cannot repair worn synchronisers, clutch plates or valve bodies.
Skyhook damping needs electrical and mechanical checks
Electronically controlled dampers use acceleration/position inputs and commanded valving. A ride-control warning can come from supply, wiring, sensor, damper or control unit. Check physical leakage and bush play alongside scan data.
Replacement dampers need the correct axle, option and calibration. Mixing passive and controlled parts without an engineered system can leave warnings and unpredictable response.
Levante air suspension retains stored energy
Where fitted, air struts, compressor, reservoir, valve block and height sensors control ride height. Compare corner height over time and inspect for line leakage. A compressor running often may be responding to a leak rather than causing it.
Support the body independently and depressurise diagnostically. Once the chassis is settled at its specified level, perform the relevant ride-height learning, measure geometry and verify any lamp or camera reference affected by the work.
Brake option and electronic parking work together
Disc diameter, thickness, offset, direction and material, caliper pistons and pad wear leads vary. Electronic parking-brake motors need service mode before piston movement and initialisation after assembly.
Inspect hub run-out, caliper release and hoses. Use the specified brake fluid and diagnostic bleed routine. A low pedal, leak, severe pull or parking brake that will not release prevents road testing.
Wheel choice affects brakes, hubs and Q4
Confirm diameter, width, offset, centre bore, fastener seat, load and brake clearance. Front/rear tyre sizes may differ by package, but replacement must preserve approved circumference relationships.
Inspect inner tyre edges and wheel cracks. Spacers or altered offsets change bearing and steering loads and should be assessed, declared and correctly fastened.
Electrical warnings start with loaded voltage
Weak low-voltage supply can cause gearbox, Q4, parking-brake and suspension warnings. Load-test the battery, measure terminal/ground drops and scan the complete network before module replacement.
Controllers may require security, VIN and option coding. Use stable programming power and record original configuration. Repair heat or water-damaged wiring before fitting electronics.
Driver-assistance calibration follows ride height
Camera/radar aim depends on windscreen, bumper brackets, tyre pressure, ride height and wheel alignment. Correct mechanical conditions before calibration. Keep the report as part of the repair record.
A sensor can communicate while mis-aimed
No code is not proof of alignment. Assume assistance is unavailable while warnings remain and never use emergency braking functions as a workshop test.
Symptoms establish the test boundary
| Symptom | Investigation | Boundary |
|---|---|---|
| Turbo power loss/smoke | Leaks, control, oil, fuel and exhaust temperature. | Stop for heavy smoke or fuel loss. |
| Gearbox selection fault | Voltage, clutch/pressure, fluid, mounts and codes. | Recover if engagement is unstable. |
| Q4 bind | Tyres, ratios, wheel speeds, transfer and oil. | Avoid tight loaded turns. |
| Low air-suspension corner | Leak decay, bag, pipe, valve, compressor and sensor. | No use with contact or poor control. |
| Brake/parking warning | Fluid, calipers, actuator, voltage and control data. | Do not road-test. |
| Red oil/temperature warning | Level, pressure, circulation and leakage. | Stop the engine. |
Finish against chassis, option and measured setup
- Record VIN, generation, engine, gearbox and Q4 identity.
- Confirm fitted labels and brake/suspension options.
- Capture faults, heights, pressures, fluids and tyre data.
- Control actuator movement, air pressure, fuel and high voltage.
- Use exact lubricants, coolants, seals and locking hardware.
- Restore heat shields, ducts, undertrays, clips and grounds.
- Fill and bleed at specified temperature and attitude.
- Learn clutch/gearbox and initialise parking brake.
- Calibrate height, alignment and assistance sensors.
- Verify progressively and reinspect under heat.
UK road use places limits on modifications
MOT condition includes brakes, steering, suspension, tyres, structure, lamps, visibility, restraints, emissions equipment and warning lamps. Required catalysts, DPF/SCR and control functions must remain.
Declare wheel, suspension, exhaust and software changes to the insurer. A test pass does not validate Q4 ratios, ride-height calibration or automated clutch learning.
Practical Maserati parts FAQs
Q: Are historic and modern Ghibli parts related?
A: Treat them as separate architectures.
Q: Can engine capacity identify timing parts?
A: No. Full engine and generation data are required.
Q: Does every GranTurismo use the same gearbox layout?
A: No. Identify automatic or transaxle specification.
Q: Can clutch learning repair worn friction parts?
A: No. Mechanical and hydraulic condition comes first.
Q: Is one automatic fluid suitable across Maserati?
A: No. Match the exact gearbox and fill process.
Q: Can one mismatched tyre affect Q4?
A: Yes. Compare circumference, wear and pressure.
Q: Does a Q4 warning prove transfer failure?
A: No. Test tyres, ratios, sensors and control.
Q: Does a low Levante corner prove air-strut failure?
A: No. Check pipes, valves, compressor and sensor.
Q: Can air suspension support workshop access?
A: No. Support the body independently.
Q: Can an electronic parking piston be forced back?
A: No. Use the prescribed service mode.
Q: Does wheel diameter prove caliper clearance?
A: No. Offset and spoke profile matter.
Q: Can low voltage cause several chassis warnings?
A: Yes. Test supply under load.
Q: Does MOT status prove ADAS aim?
A: No. Calibration is separately verified.
Q: What confirms a Maserati repair?
A: Correct generation data and stable calibrated operation.
