Mintex: understand the range before choosing
Mintex is TMD Friction's aftermarket braking brand. The current collection is a tightly defined group of five disc-brake pad sets: MDB2802, MDB2803, MDB2804, MDB2805 and MDB2906. They differ in dimensions, WVA reference, caliper system, wear-warning arrangement and supplied or separately required fitting parts, so the Mintex name alone cannot establish vehicle or axle compatibility.
AutoMotoPart currently lists 5 Mintex items. The largest Mintex groups are 5 brake pad set, disc brake entries. Mintex totals can change, so a category count is orientation rather than proof that a particular reference suits a vehicle, workplace or job. The exact Mintex listing, its current technical information and the item in front of you must agree.
What the Mintex page actually covers
| Product group in this range | Current entries | Selection focus |
|---|---|---|
| Brake Pad Set, disc brake | 5 | Match the complete MDB code to vehicle, axle, brake system, dimensions, WVA, sensor arrangement, accessories and current repair data before opening the pack. |
All five entries are disc-brake pad sets, but none is a general substitute for another. Width rises from 137mm on MDB2802 through 163.3, 169.3 and 165mm to 184.2mm on MDB2906; height and thickness also vary. MDB2802 names Bosch, MDB2803 Brembo PF 2.4, MDB2804 Brembo and MDB2805 Bosch, while MDB2906 names Brembo. Wear-warning wording changes from included to prepared-for, which affects the fitting plan.
Build a reliable shortlist
Treat catalogue confirmation and physical inspection as two separate gates. Catalogue data establishes the supported application; inspection confirms that the vehicle has not acquired a different axle, caliper or conversion. If code, geometry or sensor arrangement disagrees, stop and resolve the discrepancy instead of modifying a pad or loom.
| Check | Why it matters | Useful evidence |
|---|---|---|
| Vehicle identity | Derivative, axle rating, build date and option code can alter brakes | VIN and current Mintex application data |
| Brake system | Bosch and Brembo calipers use different pad geometry and hardware | Caliper casting, application note and full MDB reference |
| Pad geometry | Width, height and thickness do not capture every tab, slot or chamfer | Delivered pad compared with approved application |
| Wear warning | Included contact and prepared-for contact require different parts | Sensor quantity, connector, routing and separate MWI reference |
| Fitting parts | Screws, springs and accessories may be supplied or separately required | Box contents and single-use fastener list |
| Disc condition | New pads cannot correct an undersize, cracked or badly scored disc | Thickness, run-out, surface and manufacturer limits |
Never grind a backing plate, enlarge a sensor slot or omit a spring to make an almost-matching pad fit. The correct part should locate without forced alteration and preserve the designed sliding, piston contact and retention. Unresolved mismatch means the application choice must be revisited.
MDB2802 and MDB2803: warning equipment differs
MDB2802 is listed at 137 x 63 x 19.8mm for a Bosch system with WVA 29190. The evidence says it includes two wear-warning contacts per axle, caliper screws and accessories, and points to MBA1218 as a recommended accessory. Confirm both contacts, lead lengths, connector forms and their protected route before dismantling the vehicle.
MDB2803 is 163.3 x 67.1 x 20.9mm for Brembo PF 2.4 with WVA 29192. Its evidence names MWI0227 as additionally required and MBA1762 as a recommended accessory. That wording means the pad box must not be assumed to contain the complete warning circuit. Check whether the vehicle uses the named sensor and whether any undisturbed opposite-side lead remains serviceable under the repair method.
MDB2804, MDB2805 and MDB2906
MDB2804 is listed at 169.3 x 73.4 x 20.7mm with WVA 29200 for a Brembo system. MDB2805 is 165 x 79 x 20.8mm with WVA 29217 for Bosch. Both are described as prepared for a wear-warning indicator and both list caliper screws, but that shared wording does not make sensors, screws or fitting position interchangeable.
MDB2906 is 184.2 x 64.8 x 22.8mm with WVA 29231 for a Brembo system and is also prepared for a wear indicator. It is visibly the widest and thickest reference here, yet size alone does not identify the vehicle. Confirm axle, caliper variant, piston layout, disc and sensor requirement from current application data, especially on higher-capacity vehicles with multiple brake options.
Disc, caliper and hydraulic inspection
Before retracting pistons, inspect friction material wear on inner and outer pads. Uneven taper, one worn pad or heat damage can indicate seized slides, piston trouble, flex-hose restriction, disc run-out or mounting contamination. Fitting fresh pads without correcting the cause can produce rapid wear, pull, overheating or poor release.
Measure disc thickness at the supported points, compare with the stamped or manufacturer minimum and inspect both faces for cracks, severe scoring, corrosion, hot spots and a pronounced lip. Check hub and disc run-out by the vehicle procedure where required. Inspect caliper boots, guide pins, carrier lands and hose condition. Any fluid leak, damaged thread or seized component requires the approved repair before pad installation continues.
Clean fitting and approved contact treatment
Control brake dust without compressed-air dispersal. Use appropriate extraction or wet cleaning and suitable respiratory, eye and skin protection. Clean the carrier and pad abutments by the approved method without removing structural metal. Pads must slide as designed, but free movement is not created by filing their backing plates or leaving clips out.
Apply only the lubricant type and quantity permitted by Mintex and the vehicle procedure, at the named metal contact points. Keep friction material, disc faces, rubber boots, sensor surfaces and wheel-bolt seats uncontaminated. Do not put general copper grease everywhere; material compatibility and electronic parking-brake components matter. Replace specified one-time screws and torque all fasteners with a calibrated tool to current values.
Pedal restoration, bedding and final verification
After both sides are assembled, check hose routing, sensor clips, pad springs and caliper freedom before refitting wheels. Manage displaced fluid correctly when pistons are retracted and never allow the reservoir to overflow. With the vehicle stationary, operate the pedal until firm contact is restored; a first long pedal must be corrected before the vehicle moves.
Confirm fluid level, cap, warning lamps, electronic parking-brake status and wheel rotation. Tighten wheels by the vehicle sequence and torque specification. Follow the current Mintex bedding guidance, avoiding unnecessary hard stops or holding very hot pads against the disc. Carry out a controlled low-speed function test, then progressively verify braking, release, noise and warning operation. Reinspect for leaks, heat imbalance and fastener security as the repair procedure requires.
From identification to a checked result
| Stage | Good practice for this range | Mistake to avoid |
|---|---|---|
| Identify | Confirm VIN, axle, brake code, caliper and exact MDB application | Selecting from dimensions or brand alone |
| Inspect | Assess pad wear, disc, caliper, hose, fluid and warning circuit | Covering a seized slide or leaking component with new pads |
| Prepare | Support safely, control dust, clean approved contact areas and check parts | Using compressed air or altering backing plates |
| Assemble | Use correct hardware, sensor route, lubricant points and torque | Contaminating friction faces or reusing single-use screws |
| Restore and test | Build pedal pressure, verify warnings, bed and road-test carefully | Moving before a firm pedal and complete static check |
Record vehicle identity, axle, caliper system, MDB and WVA references, sensor and accessory codes, disc measurements, renewed fasteners, torque values, fluid observations and bedding instructions. This creates a useful safety record without implying that one successful fit proves compatibility across other derivatives.
Reading real Mintex references
The Mintex names below are examples from the current range and show why the complete description matters. They are not universal Mintex recommendations and should not be treated as a fitment list. Within Mintex, a shared family word can conceal a different dimension, connector, material, pack format, operating condition or installation side.
| Example listing | What to verify beyond the name |
|---|---|
| Mintex Braking (tmd) MDB2802 Brake Pad Set, disc brake | MDB2802, 137 x 63 x 19.8mm, Bosch, WVA 29190, two included wear contacts and accessory content |
| Mintex Braking (tmd) MDB2803 Brake Pad Set, disc brake | MDB2803, 163.3 x 67.1 x 20.9mm, Brembo PF 2.4, WVA 29192 and separate MWI0227 requirement |
| Mintex Braking (tmd) MDB2804 Brake Pad Set, disc brake | MDB2804, 169.3 x 73.4 x 20.7mm, Brembo, WVA 29200 and prepared-for warning indicator |
| Mintex Braking (tmd) MDB2805 Brake Pad Set, disc brake | MDB2805, 165 x 79 x 20.8mm, Bosch, WVA 29217 and prepared-for warning indicator |
| Mintex Braking (tmd) MDB2906 Brake Pad Set, disc brake | MDB2906, 184.2 x 64.8 x 22.8mm, Brembo, WVA 29231 and prepared-for warning indicator |
These measurements and system names help reject an obvious mismatch but cannot create a fitment. Use the full current application record, then reconcile the delivered pad, hardware, sensor and caliper on the vehicle before fitting.
Common errors around Mintex products
- Choosing a pad set from width, WVA or an old backing-plate number alone.
- Treating prepared-for a wear indicator as meaning the sensor is included.
- Mixing Bosch and Brembo hardware because pad dimensions look close.
- Pushing a piston back without inspecting fluid level, boot and caliper condition.
- Dispersing brake dust with compressed air.
- Applying lubricant to friction faces or incompatible rubber components.
- Reusing a fastener that the repair method marks single-use.
- Moving the vehicle before restoring a firm pedal and completing static checks.
Mintex questions and answers
Q: Which Mintex pads are listed?
A: MDB2802, MDB2803, MDB2804, MDB2805 and MDB2906 disc-brake pad sets.
Q: Do dimensions prove fitment?
A: No. Confirm the exact MDB reference by VIN, axle, brake option and current application data.
Q: Are all five for the same caliper system?
A: No. The evidence names Bosch, Brembo PF 2.4 and Brembo systems across the group.
Q: Does MDB2802 include wear contacts?
A: Its current evidence states two wear-warning contacts per axle; verify the delivered box and vehicle connectors.
Q: What extra item is named for MDB2803?
A: The evidence identifies MWI0227 as additionally required and MBA1762 as a recommended accessory.
Q: What does prepared for wear indicator mean?
A: The pad accepts the supported indicator arrangement; it does not prove the sensor is in the box.
Q: Should pads be replaced on one side only?
A: No. Replace them as the specified axle set and investigate any uneven wear.
Q: Can a scored disc simply receive new pads?
A: Measure and inspect it against manufacturer limits; replacement or further repair may be required.
Q: Where should brake lubricant go?
A: Only on the exact approved metal contact points and never on pad or disc friction surfaces.
Q: Can brake dust be blown away?
A: Do not disperse it with compressed air; use controlled extraction or wet cleaning with suitable protection.
Q: Why must the pedal be operated before moving?
A: Retracted pistons leave clearance, so firm pad-to-disc contact must be restored while stationary.
Q: What follows installation?
A: Verify fluid, warnings, torque and free rotation, then bed and road-test under controlled conditions.
