MAXUS Car Parts
Maxus parts selection starts with the full VIN, build date, model, wheelbase, body, plated weights and exact diesel or electric drivetrain. Deliver 9, Deliver 3, eDeliver variants, pick-ups and earlier Maxus vehicles can use different engines or motors, batteries, gearboxes, axles, brakes, suspension and electrical systems. Record axle configuration, brake option, conversion equipment and installed component numbers.
Do not select driveshaft, spring or braking parts from the exterior body badge alone.
SAIC, LDV heritage or supplier relationships can guide a reference but do not prove interchange. Mounts, shafts, springs, cooling, connector pinning, software, emissions stage and market equipment can differ. Use a VIN-supported cross-reference and confirm dimensions, loading, orientation, coding and any paired or one-time hardware requirement.
Commercial duty must be described by mileage, engine hours, payload, stop-start use and body conversion. Use plated gross, axle, train and towing limits and subtract passengers, fuel, tools, racking, tail-lift or refrigeration equipment from payload. Heavier springs or tyres do not increase authorised weights.
Diesel models need the exact oil approval, filters, coolant and aftertreatment diagnosis. DPF or SCR warnings require checks of engine temperature, air and boost path, fuelling, pressure lines, temperature and NOx sensing, emissions-fluid quality and dosing. Repeated regeneration cannot remove ash or repair an underlying fault.
Electric Maxus models require trained high-voltage isolation, verified absence of voltage and approved lifting for the battery’s mass. Keep battery, motor, charger and heat-pump circuits chemically separate. Underbody impact, coolant leakage, unusual heat, odour, hiss or smoke requires quarantine and specialist assessment.
Match brakes, hubs, wheel bearings, tyres and suspension to axle load and model phase. After steering, suspension, windscreen or bumper work, align and complete required ADAS calibration. Recover for brake or steering defects, unsafe tyres, wheel-security concerns, structural damage, oil-pressure or temperature warnings, fuel leakage or high-voltage faults. MOT compliance does not confirm payload, charger or fleet-release safety.
Your Current Vehicle
Or
Select Your Vehicle
Shop Parts by Category
Choose a category to view parts for your selected vehicle.
Vehicle Models and Options for MAXUS
MAXUS Car Part Categories
Only categories with verified fitment products are shown.
Maxus fitment begins with commercial configuration
Model name alone omits wheelbase, roof, body, axle loading, engine or motor, battery and conversion. Deliver and eDeliver families span diesel and battery-electric architectures. Pick-ups and earlier vehicles add further systems.
Record VIN, build, market, wheelbase, body, plated weights, powertrain, gearbox or drive unit, axles, brakes and conversion serials. Confirm installed labels and software identity.
LDV or SAIC history is not automatic interchange
Brand and corporate relationships can explain an engineering origin, but later revisions may change mounts, connectors, calibration, springs, brakes or emissions equipment. A part that resembles an earlier van component still needs proof.
Use a validated VIN cross-reference and compare load rating, material, dimensions and software. Keep the removed part until the working-vehicle heat cycle is complete.
Build a load and duty record
| Record | What it controls | Release value |
|---|---|---|
| VIN/body/wheelbase | Structure, shafts, brakes and suspension. | Prevents variant mismatch. |
| Gross/axle/train plates | Payload, tyres and towing. | Confirms legal limits. |
| Engine hours/duty | Oil, cooling and aftertreatment checks. | Shows idle/urban severity. |
| Battery/motor data | HV parts, lifting and thermal circuits. | Sets isolation plan. |
| Brake/tyre measurements | Axle-specific hardware and loading. | Supports road release. |
| Body conversion serial | Tail-lift, refrigeration or racking. | Preserves interlocks and payload. |
Payload is the remaining allowance, not a brochure headline
Read vehicle and axle plates, then account for driver, passengers, fuel, tools, racking, tow-ball load and permanent conversion. Weight distribution can overload one axle while gross mass remains below its limit.
Use a weighbridge when loading is uncertain. Replacement springs, air helpers or higher-rated tyres do not rewrite the plate.
Diesel service follows engine and emissions stage
Use exact oil viscosity and approval, filter, capacity, fuel filtration and timing data. Low-ash lubricant may be required to protect aftertreatment. Record oil level and diesel dilution.
An oil-pressure warning, fuel leak, heavy smoke or rising temperature requires shutdown. High commercial utilisation makes “finish the route” a costly response to a critical warning.
Aftertreatment faults cross several systems
DPF soot depends on thermostat, boost, EGR, injectors, pressure tubes and temperature sensing; ash is permanent accumulation. SCR efficiency depends on correct emissions fluid, dosing, mixing and NOx feedback.
Regeneration is a controlled heat event
Verify calculated loading and prerequisites and clear combustible materials from the exhaust area. Forced regeneration cannot remove ash or correct a failed injector, thermostat or dosing valve.
Unit-specific fluids prevent driveline damage
| Unit | Required identity | Unsafe shortcut |
|---|---|---|
| Diesel engine | Engine, emissions stage and oil approval. | Generic fleet oil. |
| Manual/automatic gearbox | Exact unit, fluid, filter and fill state. | Selecting by selector or gears. |
| Drive axle | Axle, ratio and lubricant. | Using gearbox oil. |
| Cooling system | Engine or EV circuit chemistry. | Mixing by colour. |
| EV reduction unit | Motor/gear unit and service method. | Calling it universal ATF. |
| Brake hydraulics | Specified fluid and diagnostic bleed. | Ignoring a falling level. |
Electric variants require a different workshop boundary
Trained personnel should secure keys, charging and remote wake-up, follow the exact isolation and wait period and prove de-energisation with suitable equipment. A stationary silent van may remain live.
Establish an exclusion zone and record the isolation. The disconnected 12-volt battery is not proof that high voltage is absent.
Battery lifting and impact need commercial-scale planning
A large van battery is extremely heavy and broad. Use approved vehicle pads and a rated balanced table. Underbody panels or the pack enclosure are not improvised jacking surfaces.
After grounding or collision, assess deformation, leakage, temperature, odour, noise and smoke. Quarantine a suspect vehicle and do not charge it.
Charging faults should be separated by supply type
Record AC or DC failure, state of charge, temperature and charger message. Inspect inlet lock, contacts, water paths and heat while safely isolated. Causes can include supply, cable, inlet, onboard charger, DC path, battery or thermal control.
Restore seals and drainage after inlet work and complete protective-earth, insulation and communication checks before charging release.
Commercial brakes need axle and temperature evidence
Measure disc/drum condition, pad/shoe thickness, caliper or cylinder movement, hoses, pipes, parking hardware and wheel bearings. Match friction and hydraulic specification across each axle.
Electronic parking-brake systems require service mode. After bleeding, verify pedal reserve, measured balance, free rotation and hub temperature under a representative load.
Wheel security deserves a recorded process
Clean and inspect wheel/hub faces, studs or bolts, threads and seats. Follow the specified lubrication condition, sequence and torque. Paint, corrosion or grease on a clamping face can reduce retention.
Use the manufacturer/operator recheck policy after wheel disturbance. Rust trails, clicking or movement marks require immediate immobilisation.
Tyres must carry the real axle load
Use approved size, construction, load/speed rating and pressure for the axle and duty. Twin or single arrangements must be correctly paired where applicable. Inspect inner walls and tread hidden by the body.
A tyre pressure suitable when empty may not suit maximum load. Use the stated data and confirm actual axle weights.
Suspension condition changes with body conversion
Inspect springs, dampers, bushes, ball joints, steering links, subframes or chassis brackets and bump stops. A tail-lift or racking can maintain a permanent rear load even when the van appears empty.
Set ride height and alignment under specified conditions. Tighten bonded joints in their normal position and verify headlamp aim.
Bodybuilder equipment has separate safety data
Tail-lifts, refrigeration, tipper or welfare equipment can add hydraulics, high current, stored pressure and interlocks. Use the body serial, rated load and maker’s service instructions.
Never diagnose movement inside the danger zone
Support raised equipment mechanically, isolate energy and release pressure. A hydraulic pinhole can inject fluid through skin and requires urgent medical attention.
Low-voltage supply manages both diesel and EV systems
Test battery condition, alternator or DC-DC output, grounds and cable drop under working accessory load. Added trackers, refrigeration controls or chargers can change drain.
Use fused, rated circuits and documented isolation. A larger battery does not repair a parasitic draw or poor ground.
ADAS calibration follows vehicle geometry
Windscreen, mirror, bumper, radar, suspension and alignment work can alter assistance references. Confirm tyre pressures, ride height, glass and sensor brackets first.
Use the specified target and calibration method. A fault-free scan does not prove aim, especially after body conversion or collision.
Cargo restraint and body structure share the load
Inspect bulkhead, floor, lashing points, doors, hinges, locks and any racking attachment. General self-drilling screws do not create a rated cargo anchor. Loads must be restrained against braking, cornering and impact without puncturing fuel, battery, brake or wiring routes below the floor.
Door misalignment, cracked sealer or a changing aperture can indicate hinge, body or chassis movement. Repair the structure before adjusting a latch to pull the opening closed. Confirm emergency exits and internal handles after lining or conversion work.
Permanent body equipment contributes to axle load and centre of gravity. Record its mounting inspection and include it in the weighbridge and tyre-pressure plan.
Faults set the fleet release decision
| Finding | Evidence path | Decision |
|---|---|---|
| Wheel movement mark | Fasteners, wheel, hub and bearing. | Immobilise. |
| DPF warning with oil rise | Dilution, soot/ash and engine cause. | Withdraw and diagnose. |
| Long brake pedal | Leak, air, hydraulics and friction. | Do not drive. |
| Battery impact/HV warning | Enclosure, isolation and thermal state. | Quarantine. |
| Overweight axle | Weighbridge and load distribution. | Unload/reposition before travel. |
| Body equipment interlock fault | Sensor, wiring, hydraulics and control. | Do not bypass or operate. |
Return to fleet through a written release
State the released load condition, tyre pressures, wheel checks and any driver follow-up so later duty changes do not invalidate the workshop baseline.
- Confirm VIN, body, powertrain and plated limits.
- Record duty, load, faults and installed hardware.
- Control lifting, high voltage and body energy.
- Use exact fluids and axle-rated parts.
- Restore shields, clips, interlocks and seals.
- Measure brakes, wheels, tyres and alignment.
- Complete charging or emissions readiness checks.
- Calibrate assistance systems.
- Test at controlled load and temperature.
- Record follow-up and daily-check points.
MOT and operator duties are continuous
The applicable UK test depends on vehicle class and use, but no pass authorises overweight operation or a known defect. Brakes, steering, tyres, wheels, structure, lights, visibility, emissions and restraints must remain safe.
Operators should maintain defect reporting and daily checks. Declare conversions, powertrain, suspension, wheel and software changes to the insurer and relevant authorities where required.
Practical Maxus parts FAQs
Q: Is the Maxus model name enough for parts?
A: No. Wheelbase, body, powertrain and weights matter.
Q: Do LDV references always fit later Maxus vans?
A: No. Verify VIN and complete specification.
Q: Do stronger springs increase legal payload?
A: No. Plated limits remain unchanged.
Q: Can regeneration remove DPF ash?
A: No. Ash is non-combustible.
Q: Is a silent electric van de-energised?
A: No. Isolation must be proven.
Q: Can a battery enclosure support a jack?
A: No. Use approved structural lifting pads.
Q: Is a charging problem always the battery?
A: No. Supply, inlet, charger and thermal causes exist.
Q: Should wheel torque be recorded?
A: Yes. Use the specified condition and recheck policy.
Q: Can tyre pressure ignore commercial load?
A: No. Use actual axle load and approved data.
Q: May a tail-lift interlock be bypassed?
A: No. Restore its designed safety operation.
Q: Is alignment enough after windscreen work?
A: No. ADAS calibration may also be required.
Q: When should a Maxus be immobilised?
A: For wheel, brake, steering, weight, body or HV hazards.
Q: Does an MOT confirm payload compliance?
A: No. Actual plated loading must be checked.
